Intelligent højindgang med EPS (Error Protection System) / Start-stop klar, automatisk tændingsfunktion / Burr-Brown konverter (PCM3168A) og Analog Devices DSP (ADAU1452) / Dual 32bit, 330 MHz DSP-teknologi, styrbar via den nye V3 DSP software og V3 app / Soft-clipping (effektreduktion) ved 2 Ohm drift / Signal-støjforhold ≥90dB / Frekvensområde 15 Hz – 22 kHz (-3dB) / Forvrængning ≤0,1% (1 kHz, 4 Ohm, 90% effekt) / Separat justerbar indgangsfølsomhed (kanal 1-4, kanal 5-6), Clipping LED / Plug+Play med køretøjsspecifikke kabelsæt / Ekstern Bluetooth® USB-dongle BTS, BTS-HD & BTA2 til audiostreaming & app-styring (valgfrit) / Digital fjernbetjening DRC1 med OLED-display til styring af diverse DSP-funktioner (valgfrit) / Quick Connect-terminal til tilslutning af MUSWAY subwoofersystemer
Features:
• Intelligent High Level Input (Error Protection System)
• Start-Stop ready, Auto Turn-On
• Burr-Brown converters (PCM3168A) and Analog Devices DSP (ADAU1452)
• Dual 32bit, 330 MHz DSP technology, controllable via new V3 PC software or V3 App
• Soft-Clipping (power attenuation) in 2 Ohm operation
• Signal-to-noise Ratio ≥90dB
• Frequency Response 15 Hz – 22 kHz (-3dB)
• THD ≤0,1% (1 kHz, 4Ω, 90% Power)
• Separately controllable input sensitivity (Channel 1-4, Channel 5-6), Clipping LEDs
• Plug+Play with vehicle-specific cable sets
• External Bluetooth® USB-Dongles BTS, BTS-HD & BTA2 for Audio Streaming & App Control (optional)
• Digital remote control DRC1 with OLED display for controlling various DSP functions (optional)
• Quick Connect Terminal to connect MUSWAY Subwoofer Systems
Specifications:
6 x 70/105 Watts RMS @ 4/2 Ohms or
3 x 210 Watts RMS @ 4 Ohms bridged
6 x High Level Input 4,8 – 20 V/RMS
6 x RCA Low Level Input* (RCA) 2 – 6 V/RMS
1 x AUX Input/Stereo (RCA) 2 – 6 V/RMS
1 x Optical Input/Stereo (PCM, 96 kHz / 24 bit)
6 x Loudspeaker Output amplified
2 x Pre-Amplifier Output (RCA) 4 V/RMS (configurable via DSP)
Dimensions: 150 x 44 x 220 mm
* only with optional MPK-RCA6/MPK-RCA6-PP cable set
